Small powerfull unit IC 022 EVO for fine cleaning

Discover a new dimension in surface cleaning with our revolutionary two - hose dry ice blasting system


Parameters

Material

Casing: Fibreglass
Wheel frame: Stainless steel

Weight

Low weight: only 19 kg

Hopper capacity

4 kg

Air consumption

1,1m³/min


Characteristics

Dry ice blasting has never been so affordable! Discover a new dimension of surface cleaning!

Dry ice cleaning is now also available to car workshops, car dealerships, all manufacturing or maintenance companies in any industry, big or small. We bring you a cost-effective alternative to traditional cleaning methods.

The unique design of the IC 022 EVO offers surprising flexibility, performance and power. The maintenance-free feeding system from ICS accepts both 1,5 mm and standard 3 mm dry ice pellets.

The excellent design of the blaster allows easy handling even in tight access spaces. The operation of the machine is easy and fast to get used to.

With IC 022 EVO you are equipped to manage very wide variety of cleaning tasks.

IC 022 EVO with its unique feeding system offers unrivalled performance at an unbeatable price.


3D view




Examples of use


For download

Dimensions
Consumption
Weight
Length: 528 mm
Dry ice: to 24 kg/h
Empty machine: 19 kg with the hose
Width: 296 mm
Compressed air: 1,1 m³/min. depending on the nozzle type
and blast gun
Height: 336 mm





Operating pressure
Hopper capacity
ISO 8573-1:2010 [1:4:1]
8 – 10 bar (116 - 145 PSI)
4 kg
0,1 mg/m³ Particles Class: 1


DTP 3°C Water Class 4
Material
Noise level
0,01 mg/m³ Class 1 oil 1
Casing: Fibreglass, Wheel frame: Stainless steel
65-85 dB(A) depending on the blasting


pressure and the cleaned surface

Compressed air supply


NW 7.2 coupling, acc. ISO
Imput pressure

4414/EN 983 standard
up to 10 bar (145 PSI)
